(1588 kg).Ĭontact Us to Get a Quote Click to learn about ISAT's Vibration Isolation engineering services. Operating static deflections are available up to 2.00" (51 mm), in capacities of up to 3500 lbs. Support of vertical pipe risers, where upright motion must be limited, yet the riser isolated from the building. Isolate vibration produced by equipment subject to weight change or external forces, such as air-cooled condensers, fans, and other rooftop equipment. Some restrained spring isolators are designed to provide seismic restraint as well. Operating static deflections are available up to 4" (102 mm) to compensate for long span flexible floor structures and maintain a high degree of noise and vibration isolation. Vibration isolators for mechanical equipment, when the equipment to be isolated has significant changes of weight during maintenance operations, and for equipment subjected to external forces or high wind loads. (10,523 kg) to compensate for long span flexible floor structures. Operating static deflections are available up to 4" (102 mm) and with load capacities to 23,200 lbs.
The model FDS can also be used in conjunction with wind or seismic restraint and installed outdoors. Highly effective for control of both high and low frequency vibration produced by fans and pumps located in floors. There is NONE BETTER for Engineering services, manufacturing and testing capabilities - all backed by the industry’s most experienced staff.įree-Standing Spring Isolators (Model FDS) This grants flexibility in challenging physical environments without compromising the effectiveness of these products.Ī) Rated load is the maximum load recommended.ISAT and Kinetics vibration isolation spring isolaters. The standard design of the elastomer and vibration isolator hanger allows for an angular misalignment of up to 30 degrees. Our extensive inventory of elastomer and spring hangers range from economical, light duty hangers, and powerful, heavy duty hangers with maximum load ratings that reach as high as 1,900lbs. Isolation bases are provided height savings bracket at each of the four corners and are available with optional spring floor (SF) or housed spring floor isolators (set of four required.) (Isolators are not included with the base unless otherwise specified. With proper isolation, these inefficiencies can be eliminated or negated to a large degree. An adjustable motor slide base is required for motor mounting on Arr. Reduce Energy Consumption: Increased vibrations can cause malfunctions in machines, requiring more energy to operate at optimal power and speed. With appropriate vibration isolation, however, this disruption can be avoided. Prevent Disruption: Certain sensitive equipment is particularly susceptible to vibrations. A vibration isolator hanger can reduce this frequency. Reduce Maintenance: Vibrations caused by a machine can loosen its bolts and screws, requiring more downtime and maintenance in the long run. While vibration isolation is essential for protecting the building from vibrations, they also serve other key functions.
As a result, these isolation hangers are required in HVAC industries, as well as building and construction to isolate suspended equipment from vibrations transferred from rotating equipment and water pipes. Some prominent applications of vibration isolator hangers include pipes, ducts, fans, air control, and other suspended structures on or within a building. Note: When product price is not shown, please call our office for technical consultation prior to place an orderĪ vibration isolator hanger uses a spring that helps dampen the vibration coming from machines or devices that are suspended. These dampeners are used across all the mechanical rooms and equipment in the buildings. Spring vibration isolators/hangers are used for suspended equipment, such as: fans, coil units, air circulation units, pipes, ducts, and other hanging structures. Spring in side the housing are colour coded for an easy identification.
All vibration isolator elements are fail safe and tested. Spring isolator will accomodate 50% overload on the published rated load of the spring for the safety and occasional shocks. Antivibration elastomer cups reduce the transfer of vibrations and noise. Elastomer cups at the base and top of the spring have vulcanized steel washers to provide even and uniform distribution on the bottom plate of the steel housing. This design of our spring hanger for ceiling and suspended applications considerably increases the rigidity of the steel frame, eliminating the possibility of the bending of the frame's bottom plate under heavy loads. HA-S, HB-S, HC-S, and HD-S models are heavy duty antivibration spring hangers and incorporate a new design of steel housing, with the base's two sides bent down.
